1.PRODUCT FEATURES
2.PRODUCT DIMENSION
| Overall height | h1 | 2037 mm |
| Lifting height | h3 | 210 mm |
| Fork face ground clearance (with lowest fork) | h5 | 85mm |
| The height of the charging brush plate above the ground | h6 | 500 mm |
| Overall length | L1 | 1720mm |
| Vehicle length (without forks) | L2 | 481 mm |
| Overall width | b1 | 980 mm |
| Fork size (length/width/height) | l/e/s | 2450/180/55 mm |
| Width of fork (outside) | b5 | 680 mm |
| Wheelbase, drive side | b10 | 498 mm |
| Wheelbase, load side | b11 | 500 mm |
| Minimum ground clearance | m1 | 30 mm |
| Minimum turning radius (with highest forks) | Wa | 1460 mm |
| Minimum right angle stacking channel width (with highest forks) | Ast | 1915+200 mm |
| Right angle stacking channel width, pallet 1000×1200 (1200 placed along the fork, with highest forks) | Ast | 2030+200 mm |
3.SPECIFICATION
[1]. Designed for indoor transport, not recommended for outdoor environments. [2]. Road surface is smooth, clean and without significant undulations. Slope 5% = arctan(0.05) ≈ 2.8°. The robot may not stop or turn at ramps, steps, or gaps, but may only pass quickly perpendicular to them. [3]. Navigation accuracy usually refers to the repeated accuracy of the robot navigation to the target site. When the environment scanned by the robot LiDAR is relatively stable (change rate <30%), the repeated accuracy of the robot navigation from the fixed direction to the target site can reach the expected value. When the robot runs along the virtual path, it will try to fit the path, but it does not guarantee repeatability. That is, the robot can guarantee the accuracy of the point, without guaranteeing the accuracy of the navigation path. The minimum site spacing supported by the robot is 1cm. [4]. The basic functions include map editing, model editing, positioning and navigation, basic motion model (differential), API interface, etc.
4.COMPANY PROFILE
Shenzhen WellWit Robotics Co., Ltd was established in Shenzhen in March 2015, who is a professional ODM/OEM provider specializing in Autonomous Mobile Robots(AMRs) for system intergrators across diverse industries.
Wellwit Robotics has three major AMR platforms: the CE platform, UL platform, and Non-CE platform, ensuring compliance with various safety standards worldwide.In addition, we are planning our manufacturing capabilities in Vietnam, creating a robust supply chain strategy of "Designed in China, Manufactured in Vietnam, Delivered Locally."
Wellwit Robotics is dedicated to becoming the premier AMR ODM/OEM service provider, delivering safe, reliable, and innovative AMR product solutions to customers around the world.
Specific prices can be discussed in person, we have different configurations, so the prices will be different for different AGV/AMR.
| Payload (kg) | 3000 |
| Speed (m/s) | 1.5 |
| Battery (h) | 8 |
| New / Used ? | New |
